| Plant Type | MCP-20 | MCP-30 | MCP-45 |
|---|---|---|---|
| Inline Bin | 3.5 Cum (Each) | 6 Cum (Each) | 8 Cum (Each) |
| Nos. of Bins | 3/4 | 3/4 | 3/4 |
| Charging Conveyor | Chevron - 600 mm | Chevron - 800 mm | Chevron - 800 mm |
| Mixer Type | Turbo Pan / Twin Shaft | Turbo Pan / Twin Shaft | Turbo Pan / Twin Shaft |
| Mixer H.P. | 20 | 30 | 40 |
| Mixer O/P Cap. | 20 cum/hr | 30 cum/hr | 40 cum/hr |
| Batch Size | 0.375 cum | 0.5 cum | 0.75 cum |
| Cement Weigher Cap. | 150 Kg. | 300 Kg. | 450 Kg. |
| Water Weigher Cap. | 100 Ltrs. | 150 Ltrs | 250 Ltrs. |
| Additive Cap. | 15 Ltrs. | 15 Ltrs. | 15 Ltrs. |
| Screw Conveyor | 168 - 10 Mtr | 168 - 10 Mtr | 219 - 11 Mtr |
| Manual Feeding Hopper Cap. | 1 Cum | 1 Cum | 1.5 Cum |
| Plant Discharge Height | 4100mm | 4100mm | 4100mm |
| Operator Cabin | 5' X 5' X 7' | 5' X 5' X 7' | 5' X 5' X 7' |
