| Plant Type | 120 | 160 | 200 |
|---|---|---|---|
| MAX output | 120 t/h | 160 t/h | 200 t/h |
| Batch Size | 1.5 t | 2 t | 2.5 t |
| Cold feeders | 4/5/6 | 4/5/6 | 4/5/6 |
| Cold feeders: capacity and number | on customer request | ||
| Type drying drum | (L=7.5 m/D=1.80 m) | (L=8.5 m/D=1.80 m) | (L=8.5 m/D=2.06 m) |
| Burner power output | 7 MW | 9 MW | 13.4 MW |
| Hot elevator capacity | 140 t/h | 180 t/h | 220 t/h |
| Hot aggregate bin unit | 4/5/6 | 4/5/6 | 4/5/6 |
| Screen surface total area | 4 sel.= 14.6 m2/5 sel.= 17.6 m2 | 4 sel.= 16.5 m2/5 sel.= 20.8 m2 | 5 sel.= 26.9 m2/6 sel.= 32.1 m2 |
| Screening | 5 (6 as an option) + 1 separate by-pass | ||
| Hot aggregate bins | 17.3 t | 20 t or 52 t | 20 t or 52 t |
| Aggregate Scale | 1600 kg | 2100 kg | 2600 kg |
| Filler Scale | 300 kg | 300 kg | 400 kg |
| Bitumen Scale | 225 kg | 225 kg | 300 kg |
| Mixer capacity | 1600 kg | 2100 kg | 2600 kg |
| Pollution control unit | Bag house filter - Reverse airflow | ||
| Filter surface | 413 m2 | 525 m2 | 663 m2 |
| Control panel type | fully computerized with manual over-ride | ||
| Bitumen tank capacity | 15 / 25 / 30 / 50 m³ - Direct heating / Thermic oil heating | ||
